What are Server Processes

A server process can be defined as one with the following behaviour :

• Long running process.
• It can maintain state.
• It can process messages and react to them.
• It may modify the internal state.
• It may send a reply back to the client.

Server processes are important in building highly concurrent systems. Erlang provides an important abstraction to handle server processes in it’s portion of OTP framework, known as a Genserver. It’s the essential backbone over which much of the parallel processing in Elixir is built.

Implementing the Server Process

Inorder to have a better understanding of the Genserver behaviour. Let’s build a minimal version of this abstraction ourselves using the very basic construct of OTP, processes. To do this, we have to implement a process which has all the characteristics mentioned above, of a long running server process.

What we want to achieve at the end:

1. Define a behaviour(for a long running process with state) which can be extended
  using callback modules.
2. The behaviour should create a process and initialize it by calling the
   respective callback module.
3. The behaviour should have a mechanism to keep the process runnning until a signal
   to stop or kill the process is given.
4. The behaviour should expose interface functions to deal with the server process.
5. The interface functions should include functions to make synchronous and
   asynchronous calls to the process.

First steps first, create a new project with :

    mix new server_process

Inside your project create a module ServerProcess.GenericServer in

lib/server_process/generic_server.ex.

This module will handle our generic code(start process, maintain state etc.) implmentation, the specifics of which(e.g. initalizing state, processing, etc.) would be handled by a concrete implementation. These implementations can be done using callbacks. (will become more clear as we move forward).

defmodule ServerProcess.GenericServer do
	def start(callback_module) do
		spawn(fn ->
			initial_state = callback_module.init()
			loop(callback_module, initial_state)
		end)
	end
  ...
end

GenericServer.start(callback_module) takes a module name, and spawns a process with the initial state, being set by a function init() exposed in the callback_module. In order to enforce this rule of exposing the init function we can use behaviours.

defmodule Server.GenericServer do
	@callback init()
...
end

With this change all the callback modules implmenting the GenericServer behaviour will have to implement the callbacks added.

Next step would be to add the loop(callback, state) function. The loop function makes use of a tail recursion call to maintain the state and keep the process running forever using infinite recursion.

defmodule Server.GenericServer do
  @callback init() :: any
  @callback handle_call(request :: tuple(), state :: any) ::
    	{response :: any, new_state :: any}
  @callback handle_cast(request :: tuple(), state :: any) :: {new_state :: any}
  @callback terminate() :: any}
	....

	def loop(callback_module, state) do
    new_state =
      receive do  #waits for a message to come in the mail box
        {:call, from, request} ->
          {result, state} = callback_module.handle_call(request, state)
          send(from, {:result, result})
          state
		    {:cast, _from, request} ->
			    callback_module.handle_cast(request)
        {:stop, _from, reason} ->
          callback_module.terminate()
          Process.exit(self(), reason)
        end

    loop(callback_module, new_state)
  end
  .....
end

The loop/2 function handles the generic logic of sending and receiving messages, the specific logic of what to do with the request is handled by the callback module’s handle_call/2 and handle_cast functions. This brings us to the next set of callbacks that should be implemented. The last callback terminate allows us to perform any cleanups before terminating our genserver with Process.exit/2.

Whenever we are using tail recursion inside loop function with a receive block, the process waits for any message to come in its mailbox and executes it when it receives one. One important thing to note here is that when a process is waiting for a message at receive, it is put in a suspended state. This prevents wastage of any CPU cycles for the process.

A request can be synchronous or asynchronous depending on the requirement. To differentiate between them we use :call(synchronous) and :cast(asynchronous) going with the convention in Erlang. In a synchronous request the calling process waits for a response from the server process. This blocks the client for the duration in which processing happens. In an asynchronous the client doesn’t expect a return value so it just sends the request and continues with its work. The requests are pattern matched to continue with further execution, all the requests coming in must be tagged with :cast or :call.

Now that our long running process with state is started, let’s move on to writing the interface functions which will help us in interacting with this process. The functions we would implement are:

• cast: makes an aysnchromous call, starts the processing and returns.
• call: makes a synchronous call and returns with the value after processing.
• stop: stops the server process with provided reason.

defmodule ServerProcess.GenericServer do
  ....

  def cast(pid, request_params) do
    send(pid, {:cast, self(), request_params})
  end

  def call(pid, request_params) do
    send(pid, {:call, self(), request_params})

    receive do
      {:result, result} ->
        IO.puts(result)
    end
  end

  def stop(pid, reason) do
    send(pid, {:stop, self(), reason})
  end

  ....
end

The cast/2 function takes the pid of the server process and the request params that would be sent to the callback_module for processing. Internally it calls the Kernel.send/2 with the pid and {:cast, self(), request_params}. This will send a message to the mailbox of our server process. On receiving a message the process will pattern match it, in our case it is {:cast, _from, request} inside the receive block, which will further call the handle_cast callback in the callback_module we initiated our process with.

The call/2 function similarly takes the pid and the request params and sends a message to the process mailbox using Kernel.send/2. However, since we are expecting a result we make use of a receive block. Processes in elixir interact with each other using the process mailbox. As can be seen from the loop block that the server process sends a message back to the calling process. The receive block prints any message received for our client process.

The stop/2 function takes the pid and reason(:normal, :kill). The function sends a message to the our server process with a reason for termination. On receiving the message the server_process makes a call to terminate callback in the callback module to perform cleanups and then terminates itself.

This is our server process module in it’s entirety.

defmodule ServerProcess.GenericServer do

  ############### interface functions ############
  # The following functions are run in the client context
    def start(callback_module) do
    spawn(
      fn ->
        initial_state = callback_module.init()
        loop(callback_module, initial_state)
      end
    )
  end

  def cast(pid, request_params) do
    send(pid, {:cast, self(), request_params})
  end

  def call(pid, request_params) do
    send(pid, {:call, self(), request_params})

    receive do
      {:result, result} ->
        IO.puts(result)
    end
  end

  def stop(pid, reason) do
    send(pid, {:stop, self(), reason})
  end

  ################ callbacks for the behaviour ######
  @callback init() :: any
  @callback handle_call(request :: tuple(), state :: any) ::
    	{response :: any, new_state :: any}
  @callback handle_cast(request :: tuple(), state :: any) :: {new_state :: any}
  @callback terminate() :: any

  ################ server calls #################
  # The following functions are run in the server process context

  def loop(callback_module, state) do
    new_state =
      receive do
        {:call, from, request} ->
          {result, state} = callback_module.handle_call(request, state)
          send(from, {:result, result})
          state
		    {:cast, _from, request} ->
          callback_module.handle_cast(request, state)
        {:stop, _from, reason} ->
          callback_module.terminate()
          Process.exit(self(), reason)
      end

    loop(callback_module, new_state)
  end

end

Creating a Callback Module

Let’s implement a callback module to test out our generic server. We will create a simple key value store and implement the callbacks defined by the behaviour.

defmodule ServerProcess.ExampleModule do
  @moduledoc """
  Simple key value store that extends generic server behaviour.
  """

  @behaviour ServerProcess.GenericServer

  @impl true
  def init() do
    %{}
  end

  @impl true
  def handle_call({:get, key} = _message, state) do
    result = Map.get(state, key, "not found")
    {result, state}
  end

  @impl true
  def handle_cast({:put, key, value} = _message, state) do
    Map.put(state, key, value)
  end

  @impl true
  def terminate() do
    :ok
  end

end

We use the @behaviour key to use our ServerProcess.GenericSServer behaviour. We implement the callbacks mentioned and make use of pattern matching on the messages we are receiving.

• init(): Initiates our process with map that is placed in the process state.
• handle_call({:get, key} = _message, state): receives a {:get, key} message to find the key in our state map and returns with the result and state.
• handle_cast({:put, key, value} = _message, state): receives a message to put a key in the state and returns the state.
• terminate: performs any cleanup.

Let’s try this out in an iex shell

$server_process-> iex -S mix
iex(1)> alias ServerProcess.GenericServer
ServerProcess.GenericServer
iex(2)> alias ServerProcess.ExampleModule
ServerProcess.ExampleModule
iex(3)> pid = GenericServer.start ExampleModule
#PID<0.151.0>
iex(4)> Process.alive? pid
true
iex(5)> GenericServer.cast pid, {:put, :lang, "Elixir"}
{:cast, #PID<0.147.0>, {:put, :lang, "Elixir"}}
iex(6)> GenericServer.call pid, {:get, :lang}
Elixir
:ok
iex(7)> GenericServer.stop pid, :normal
{:stop, #PID<0.147.0>, :normal}
iex(8)> Process.alive? pid
false

We are able to run all our functions. This brings us to the end of the blog.

Summary

We implemented the GenServer Behaviour ourselves, we created it a manner that heavy lifting of initializing server process and maintaining the state is handled by generic code, whereas the specifics are being handled by using callback module. The callback module implements callbacks we created in the behaviour. Although, we can create such an abstraction ourselves it’s important to use the abstractions provided by OTP as they are much more stable and provide other functionalities which are crticial for our application.
